Hvs

Basic Info.

Model NO.	HVS-1000
Application	Metal, Plastic, Ceramics and Glass, Stone
Standard	ISO, ASTM, GB/T, BSEN
Warranty	1 Year
Mobility	Portable
Calibrating Method	Standard Hardness Test Blocks
Rated Voltage	220V
Support Language	English
Customized	Customized
Delivery	3-7days
Package	Plywood Standard Export Package
Operation	1000mm Customized Can Be
Cosumption	Yes Included
Working Video	Supply
Funtion,	for Lab Service Hardness Report
Inspection	Pre-Shipment Quality Testing
Shipment	Ocean/Air Others
Type 1	Superfical Testing
Unit	5-650hbw
Usage	Metal Plastic Others
Customzied	Acceptable
Weight	210kgs
Test Force	750, 1000, 3000kgf (Optional 187.5, 250, 500,)
Testing Range	32—650hbw
Transport Package	Plywood Case
Specification	1500X1000mm (customizable)
Trademark	CJ or OEM
Origin	China Jinan or Others
HS Code	9024102000
Production Capacity	5000 Sets Per Year

Packaging & Delivery

Package Size 68.00cm * 65.00cm * 70.00cm Package Gross Weight 55.000kg

Product Description

Digital Micro Vickers Hardness Tester for Metal Plastic Material Hardness Universal Measure with Hvs-1000z with CCD Software Brinell Rockwell Testing MachineAuto Digital Micro Vickers Hardness Test Machine Hvs-1000z with CCD Software

Features:
The HVS-1000 digital microscopic Vickers hardness tester adopts a unique and precise design on the mechanics, optics and light source to make the indentation imaging clearer and the measurement more accurate. Equipped with digital display micrometer eyepiece, no need to look up the table or input the diagonal of the indentation, the test method, test force, indentation length, dwell time, conversion ruler can be displayed on the screen, and only need to measure the indentation and press the eyepiece during operation Encoder button can automatically calculate the hardness value and display it on the screen. The data results can be output via a printer. Optional Knoop indenter for Knoop hardness measurement, and optional CCD image automatic measurement system.
Introduction:
1. The result is displayed on the LCD screen, and the test scale, test force, indenter type, dwell time, conversion unit, etc. can be displayed and set
2. The fuselage is made of high-quality cast iron by one-time casting, and the car paint treatment process is used to make the appearance sleek and beautiful;
3. The turbine worm lifting system can better improve the test stability and test accuracy, and there is no need to focus again after the test is completed;
4. High-definition measurement and observation-the combination of dual objective lenses, combined with a high-definition micrometer eyepiece with a built-in length encoder, realizes one-key measurement of the indentation diagonal, which better reduces human operation interference and reading errors;
5. Convenient numerical control system, which can automatically perform unit conversion of the full hardness scale;
6. CCD image processing system is optional, and Knoop indenter is optional for Knoop hardness measurement;
7. It is equipped with a wireless Bluetooth printer and can output data through the RS232 interface;
8. Accuracy meets GB/T4340.2-2018 ISO6507-2 and American ASTM E384.
Appliance:
1. Ferrous metals, non-ferrous metals, IC flakes, surface coatings, laminated metals;
2. Glass, ceramics, agate, gems, thin plastics, etc.;
3. The depth and gradient hardness test of the carbide layer and quenched layer.
4. It is suitable for precision micro Vickers hardness measurement of parallel planes, tiny parts and ultra-thin parts.
Technical Data:

Model	HVS-1000
Measuring range	5-5000HV
Test force	0.09807,0.2452,0.4904,0.9807,1.961,2.942,4.904,9.807N (10,25,50,100,200,300,500,1000g)
Data input method	Automatic
Turret way	Manual
Maximum allowable height of test piece	120mm
Distance from center of indenter to machine wall	110mm
XY table size	100*100mm
XY worktable stroke	25*25mm
Minimum unit of XY worktable	0.01mm
Lens magnification	10×,40×
Magnification	100×,400×
Minimum step	0.025μm
Hardness resolution	0.1HV
power supply	AC 220V,50Hz
Dimensions	530*290*490mm
weight	45kg

Accessory List:

XY workbench	1PC	Thin axis test bench	1PC
Thin section test bench	1PC	Small flat-nose pliers test bench	1PC
Big V block	1PC	Small V-shaped block	1PC
Diamond Vickers Indenter	1PC	Standard microhardness block	2PCS
printer	1PC
